Metal Raschig Ring Stainless Steel Raschig Ring Cylinder For Regeneration Tower Packing

Name: Metal Raschig Ring Stainless Steel Raschig Ring Cylinder For Regeneration Tower Packing
Brand: NKCHEM
Price: 460.00 USD

China Metal Raschig Ring Stainless Steel Raschig Ring Cylinder For Regeneration Tower Packing wholesale

Brand Name : NKCHEM

Model Number : NK-MCR

Certification : ISO9001:2008

Place of Origin : CHINA JIANGXI

MOQ : >= 1 cubic meters

Price : $460.00+cubic meters

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram, L/C, D/A

Supply Ability : 1 - 1000+kilograms+PER DAY

Delivery Time : 5-8work days

Packaging Details : Conventional packing

Application : mass transfer media, Absorption, scrubbing and stripping services

Material : AISI304,cardon steel,stainless steel

Product name : Stainless steel raschig ring

Shape : raschig ring, Cylinder

material : stainless stee, carbon steel, alumina

Color : metal

Size : 15mm 25mm 38mm 50mm 76m

Keywords : metal raschig ring

classfication : distillation column packing, tower packing, metal random packing

Contact Now

Metal Raschig Ring Stainless Steel Raschig Ring Cylinder,raschig Ring(mcr) for Regeneration Tower Packing 1m3

Metal Raschig ring(MCR) for Regeneration tower packing

Metal rasching ring is made of materials like carbon steel, stainless steel or Aluminum alloy, etc.

The product has features such as thin wall, heat resistant, high free volume, high capacity, low resistance, high separation efficiency and so on.

It is especially suitable for rectification towers under vacuum to treat thermosensitive, decomposable, polymerizable or cokable systems, so it is widely used in packing towers in petrochemical industry, chemical fertilizer industry and environmental protection, etc.

Technical data

Size mm	Bulk density kg/m3	Number per m3	Surface area m2/m3	Free volume %
15×15×0.3	379	230000	350	95
25×25×0.4	318	51000	216	96
25×25×0.5	400	51000	220	95
35×35×0.8	430	19000	150	93
50×50×0.5	203	6500	106	97.4
50×50×0.7	285	6500	108	96.4
50×50×0.8	325	7000	109	95
76×76×0.8	212	1830	69	97.3
80×80×1.2	300	1600	65	96
90×90×1.0	236	1160	62	97

The above data is reference to material stainless steel (AISI304) in the material thickness shown.

Material available:

carbon steel, stainless steel including 304, 304L, 410,316, 316L.
