Stainless Steel Metal Structured Packing Column Packing For Distillation Column

Name: Stainless Steel Metal Structured Packing Column Packing For Distillation Column
Brand: NKCHEM
Price: 800.00 USD

China Stainless Steel Metal Structured Packing Column Packing For Distillation Column wholesale

Brand Name : NKCHEM

Model Number : 250Y,500Y,700Y

Certification : ISO9001

Place of Origin : CHINA JIANGXI

MOQ : 1 cubic meter/cubic meters(Min. order)

Price : $800.00 - $1,500.00/ cubic meter |

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram, L/C, D/A

Supply Ability : 300 set / sets per Month

Delivery Time : 5-8work days

Packaging Details : Conventional packing

Usage : Filter

Type : Black Wire Mesh, york mesh 431 demister pad

Material : SS304,SS316,SS316L

Hole Shape : Round

Product name : Stainless Steel Metal Structured Packing Column Packing

Keyword1 : Column Packing

Keyword2 : Metal structured packing

Keyword3 : Stainless Steel Structured Packing

Contact Now

Stainless Steel Metal Structured Packing Column Packing For Distillation Column (Stainless Steel Metal Structured Packing Column Packing For Distillation Column) is made of perforated plate with channel corrugation on surface, and remains structured feature of metal wire gauze packing. It strengthens uniform liquid distribution and surface wetting ability, which increase mass transfer efficiency.

Stainless Steel Metal Structured Packing Column Packing For Distillation Column detail:

Material
Stainless Steel Metal Structured Packing Column Packing For Distillation Column is available in a wide range of materials, including stainless steels, 304, 316, 316L, carbon steels, Aluminum, copper bronze etc. Other materials are available on request.

Application
Stainless Steel Metal Structured Packing Column Packing For Distillation Column with the wide range of applications.
Diameter: 0.1-12m; Pressure: Vacuum to high pressure;
Liquid load: 0.2 to more than 300 m3/m2. H;
System: Ethyl benzene/ styrene, Fatty acid, cyclohex anone/ cyclohexanol, caprolaction, etc, Absorption desorption.

The technical specification:

Type	specific surface are m2/m3	Void Volume %	Heaping Weight Kg/m3	Wave Height mm	Theoretical plate number m-1	Δ P Pa/m	Max F-factor m/s(kg/m3)0.5
125Y	125	98	85-100	25.4	1.0-2.0	150	3.0
250Y	250	97	170-200	12.5	2.0-3.0	200	2.6
350Y	350	94	240-280	9	2.0-2.5	300	2.0
500Y	500	92	360-400	6.3	4.0-5.0	180	1.8

Product Tags:

Stainless Steel Metal Structured Packing Column Packing For Distillation Column Images
